Tractor Post Driver – Side Tilt (PD23-DG) C/w Digger Bracket

Description:

Tractor Post Driver – Side Tilt (PD23-DG) C/w Rigid Digger Bracket



Manufacturer Code: PD23-DG

Supplied by: Multec Ltd



Why do you need it?

The Multec PD2 Post Driver is one of the most popular Post Drivers from our range … It is Affordable, easy to use & suitable for the very common hills & gradients that you would expect to find when fencing.

This Post driver also comes with our unique post cap with spikes to hold & prevent post damage from the hammer & this also acts as a safety feature.



PD23-DG Standard Specification:

• Three point linkage (Both Cat 1 & Cat 2 holes)
• Tested & CE Marked
• User Manual (See “Downloads” in Services category)
• 10″ Pulley wheel & wire/nylon rope system
• Self greasing system
• 350kg hammer weight as standard.
• Overall Weight: Approx. 800kg
• Three Lever External Control Valve (For Outside Control)
• Also Fitted with Digger Bracket (Min 5ton rated) Rigid control when on Digger

Three Hydraulic Rams:

1. Main Hammer Ram
2. Side Tilt Ram (Great for working on gradients, tilting left & right) Side Tilts on Tractor Only
3. Hydraulic Top-Link Ram (Also known as the Power Top-link, tilting towards & away from the tractor cab)



Choose your preferred Specification:

• PD23-DG: Keep it standard (As described above)
• PD23-DG+ (Plus Model): (Main Mast extended out & away from the 3PL for extra corner reach)
• PD24-DG-RS+ (Plus Model): (C/w 4 Lever Valve,Rock Spike & Hydraulic Extractor Ram & Extended Mast for extra corner reach)



Optional Extras:

• 350Kg Hammer (Keep it standard)
• 450Kg Hammer (Optional Extra with this upgraded hammer adding 100kg) Suitable for Min. 80hp Tractor & Min. 8Ton Rated Excavators.



Order Note: Please let us know the make & model of Excavator along with your preferred colour in the “Order Notes” box at check-out.

We may need your Excavator’s QH dimensions as shown in the drawing in the photos.



Order & Delivery information (Please Read):

After placing your order & cleared funds, you will receive a direct email within 48 hours with your “Order Dates” which will be as follows:

• Payment Date (Date of cleared funds)
• Dispatch Date (21+ working days from cleared funds)
• Arrival Date (2 working days from dispatch)

Please Note: You will need to have access for the delivery lorry, arrange a way of unloading & sign for arrival.

We also provide the courier’s full contact information before dispatch, so you can contact the courier direct if needed.
